3000 Series Aluminum Plate

The aluminum plate is formed by placing the aluminum plate in the corresponding electrolyte (such as sulfuric acid, chromic acid, oxalic acid, etc.) as the anode, and performing electrolysis under specific conditions and applied current. The aluminum plate of the anode is oxidized, and a thin layer of aluminum oxide is formed on the surface, the thickness of which is 5 to 20 microns, and the hard anodized film can reach 60 to 200 microns.

+86 15864389004

+86 15864389004

+86 15864389004

sale2@sd-tiscometal.com

Product Description

Aluminium Alloy	Thickness (mm)	Width (mm)	Temper
1050,1060,1100	0.2-2.0	800-2000	H14,H16,H24,H26
3003,3004,3105	0.2-2.0	800-2000	H14,H16,H24,H26
Standard Size	standard thickness:0.3-1.2mm
Surface	standard width:914mm/1000/1200/12120mm
	Size can be produced as per clients requirement
Surface	mill finish, flat, smooth, stucco emboss(orange peel), corrugation
Back lamination	polykraft paper, polysurlyn, kraft paper, craft paper
Polykraft thickness	about 0.1mm
Corrugation type	6x32mm( wave height 6mm ,and wave distance 32mm)
Quality Standard	ASTM B209,EN573-1
MOQ per size	1 tons
Payment Terms	TT OR LC OR DP at sight
Delivery time	Within 30 days after receipt the lc or deposit
Material Quality	Tension level, Flat, Free of defects like oil stain, Roll Marks, waves, dents, Scrath,etc A+++ quality
Application	heat insulation moisture barrier, oil field
Packaging	Standard export worthy wooden pallets, and standard packing is about 2 .5tons/pallet or 100 feet one roll
	Coil Id:508mm, eye to wall or eye to sky as per clients requirement
	or 100 feet one roll and each roll packed in one carton box, one 20' container can be loaded about 280 rolls

1)1000 Series Alloy (Generally called commercial pure aluminum,Al>99.0%)
Alloy	1050 1050A 1060 1070 1100
Temper	O/H111 H112 H12/H22/H32 H14/H24/H34 H16/H26/H36 H18/H28/H38 H114/H194, etc.
Specification	Thickness≤30mm; Width≤2600mm; Length≤16000mm OR Coil (C)
Application	Lid Stock, Industrial Device, Storage, All Kinds of Containers, etc.
2)3000 Series Alloy (Generally called Al-Mn Alloy, Mn is used as main alloy element)
Alloy	3003 3004 3005 3102 3105
Temper	O/H111 H112 H12/H22/H32 H14/H24/H34 H16/H26/H36 H18/H28/H38 H114/H194, etc.
Specification	Thickness≤30mm; Width≤2200mm Length≤12000mm OR Coil (C)
Application	Decoration, heat-sink device, external walls, storage, sheets for construction, etc.
Feature	Good rust resistance, not suitable for heat treatments, good corrosion resistant performance,well welding property, good plasticity, low strength but suitable for cold working hardening.
3)5000 Series Alloy (Generally called Al-Mg Alloy, the Mg is used as main alloy element)
Alloy	5005 5052 5083 5086 5182 5754 5154 5454 5A05 5A06
Temper	O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34H16/H26/H36 H18/H28/H38 H114/H194, etc.
Specification	Thickness≤170mm; Width≤2200mm ; Length≤12000mm
Application	Marine Grade Plate, Ring-Pull Can End Stock, Ring-Pull Stock, Automobile Body Sheets, Automobile Inside Board, The Protective Cover On Engine.
Feature	All the advantages of normal aluminium alloy, high tensile strength & yield strength, good corrosion resistant performance, well welding property, well fatigue strength, and suitable for anodic oxidation.
4)6000 Series Alloy (Generally called Al-Mg-Si Alloy, the Mg and Si are used as main alloy elements )
Alloy	6061 6063 6082
Temper	O F, etc.
Specification	Thickness≤170mm; Width≤2200mm ; Length≤12000mm
Application	Automotive, Aluminium For Aviation, Industrial Mould, Mechanical Components, Transport Ship, Semiconductor Equipments, etc
Feature	Good corrosion resistant performance, well welding property, good oxidability, easy to spray-finishing, well oxidation coloring, good machinability.
